RU-2001 Amplifier Control Unit (PM-660D)

Original price was: ฿6,800.00.Current price is: ฿5,675.00.


RU-2001   Amplifier Control Unit (PM-660D)

The RU-2001 is a microphone amplifier for the PM-660D Paging Microphone with a remote control switch and a 5-pin DIN socket. The power of the PM-660D’s internal power amplifier, and globalspeaker output can be remotely controlled from the RU-2001.

Power Requirement 12 – 24 V DC or 12 V AC adaptor

Current Consumption 60 mA

Microphone Input -62 dB*, 600 Ω, unbalanced, 5-pin DIN socket

Output 0 dB*, 600 Ω, balanced, M3 screw terminal, distance between barriers: 6.4 mm (0.25″)

Applicable Microphone PM-660D

Operating Temperature -10 ℃ to +50 ℃ (14 F to 122 F)

Operating Humidity 90 %RH or less (no condensation)

Finish Pre-coated steel plate, black

Dimensions 124 (W) × 42.5 (H) × 159 (D) mm (4.88″ × 1.67″ × 6.26″)

Weight 600 g (1.32 lb.)

Accessory Mounting bracket…………1
