TS-781 Chairman Unit

Original price was: ฿8,500.00.Current price is: ฿7,094.00.


TS-781   Chairman Unit

The TS-781 is a Chairman unit for TOA Conference system, of which compact and lightweight design makes it easy to install and store. Placing the speech button in the ON position allows a chairman to speak and disables the speaker to prevent feedback. If the speech button is placed in the OFF position, the microphone cannot be used but the speaker is turned on, allowing the voices from delegate units (TS-782) to be monitored. By pressing the priority button, the chairman unit can take precedence over any delegate units. Two types of dedicated microphones are made available for the TS-781 as optional products: the TS-773 standard type and the TS-774 long type.

Power Source 36 V DC, 30 mA or less (supplied from the Central Unit TS-780)

Output Headphones/Recording: 32 Ω (headphone)/10 kΩ, -20 dB* (recording),

unbalanced, mini jack (with VR) × 2

Internal speaker: 130 Ω, 200 mW (with Volume control)

Control Speech button: Microphone, speaker on-off control by speech switch

Priority button: Microphone, speaker on-off, other microphone cutoff, and

single-tone chime activation

Operating Temperature 0 ℃ to +40 ℃ (32 F to 104 F)

Operating Humidity 90 %RH or less (no condensation)

Finish Upper case: ABS resin, silver metalic, paint

Lower case: ABS resin, black

Dimensions 145.3 (W) × 70.7 (H) × 150.5 (D) mm (5.72″ × 2.78″ × 5.93″)

Weight 800 g (1.76 lb)

Option Extension cord: YR-780-2M, YR-780-10M

Microphone: TS-773 (standard), TS-774 (long) (select either one)
