WT-D5800   Digital Wireless Receiver

The WT-D5800 is a PLL-synthesizer controlled double super-heterodyne diversity receiver designed to be used with a UHF wireless system. Employing a digital reception system that is virtually immune to interference and noise, the WT-D5800 Wireless Receiver ensures stable radio signal reception. Additionally, this receiver features a host of convenient functions, such as external equipment control by way of contact outputs, and system status monitoring by way of its maintenance software, enabling highly reliable operation.

Power Source AC mains (supplied AC adapter must be used)

Current Consumption 350 mA (13.5 V)

Frequency Range EC4/EC7 ver.: 794 – 832 MHz, EG1/GG1/-G1 ver.: 606 – 636 MHz, RH1 ver.: 576 – 606 MHz

Channel Selectable 160 selectable frequencies

Receiving System Double super-heterodyne

Diversity system Space diversity (digital diversity)

Mixing Output MIC/LINE (selectable): -60 dB (*1) (MIC)/-20 dB (*1) (LINE), 600 Ω phone jack (unbalanced), 600 Ω XLR-3-32 type connector (balanced)

Mixing Input -20 dB (*1), 10 kΩ, unbalanced, phone jack

Antenna Input 75 Ω, BNC (phantom powering for antenna), 9 V DC, 30 mA (max)

Antenna Output 75 Ω, BNC (Gain 0 dB)

Contact Output 1 channel, no-voltage make contact output, withstand voltage: 30 V DC, control current 0.5 A max, terminal block (2pins)

Receiving Sensitivity 24 dBμV or less (Bit error rate:1E-5 or less)

Antenna Input Attenuator 0 dB/-10 dB switchable

Indicator Audio (5 steps), RF (5 steps), ANT A/B, Audio (peak), Battery alarm

Frequency Response 50 Hz – 12 kHz

Total Harmonic Distortion 0.5 % or less

Function Frequencies scanning, Feedback suppressor, Equalizer (optimizing each compatible microphone)

ID Selectable 10 patterns

Operating Temperature -10 ℃ to +50 ℃ (14 F to 122 F)

Operating Humidity 30 % to 85 %RH (no condensation)

Finish Resin, black

Dimensions 210 (W) x 44 (H) x 211.9 (D) mm (8.27 in x 1.73 in x 8.34 in)

Weight 730 g (1.61 lb)

Accessory AC adapter (*2) …1, Whip antenna …2, Rubber foot …4

Option Rack mounting bracket kit: MB-WT3 (for rack mounting one WT-D5800 unit), MB-WT4 (for rack mounting two WT-D5800 units)
